Control Arm Bush 48654 16110

OEM NO.:48654-16110

Fits to: Control Arm Bush fits Toyota Aygo Yaris Vitz Citroen C1 Peugeot 107 Front Upper

Size: Standard/OEM

Use: Aftermarket

Express Company: DHL, TNT, UPS, FedEx, EMX, etc.

Export Markets: Global

Packing: Neutral packing, or according to client's request.

Shipping Terms: FOB, CNF, CIF

Export Port: Xiamen Port, Customer appointed port is acceptable

Payment Terms: T/T, Western Union

Sample: Charge

Control Arm Bush 48654-16110

Control Arm Bush fits Toyota Aygo Yaris Vitz Citroen C1 Peugeot 107 Front Upper

Length 53 mm

Inner Diameter 12 mm

Outer diameter 32,7 mm

Steering arm type for control arm

Description Model Year kW HP cc Build

CITROËN C1 (PM_, PN_) 1.0 ­06.05 - 09.14 50 ­68 998 Hatchback

CITROËN C1 (PM_, PN_) 1.4 HDi ­06.05 - 09.14 40 ­54 1398 Hatchback

PEUGEOT 107 (PM_, PN_) 1.0 ­06.05 - 05.14 50 ­68 998 Hatchback

PEUGEOT 107 (PM_, PN_) 1.4 HDi ­06.05 - 05.14 40 ­54 1398 Hatchback

TOYOTA AYGO (_B1_) 1.0 (KGB10_) ­07.05 - 05.14 50 ­68 998 Hatchback

TOYOTA AYGO (_B1_) 1.4 HDi (WNB10_) ­07.05 - 08.10 40 ­54 1398 Hatchback

TOYOTA YARIS (_P1_) 1.0 (SCP10_) ­03.03 - 09.05 48 ­65 998 Hatchback

TOYOTA YARIS (_P1_) 1.0 (SCP10_) ­04.99 - 09.05 50 ­68 998 Hatchback

TOYOTA YARIS (_P1_) 1.3 (NCP10_, SCP12_) ­11.99 - 10.05 63 ­86 1299 Hatchback

TOYOTA YARIS (_P1_) 1.3 (SCP12_, NCP10_, SCP13_) ­04.02 - 09.05 64 ­87 1298 Hatchback

TOYOTA YARIS (_P1_) 1.5 (NCP13_) ­01.03 - 11.05 77 ­105 1497 Hatchback

TOYOTA YARIS (_P1_) 1.5 (NCP13_) ­04.01 - 09.05 78 ­106 1497 Hatchback

TOYOTA YARIS (_P1_) 1.5 (NCP13_) ­03.00 - 07.05 110 ­150 1497 Hatchback

TOYOTA YARIS (_P1_) 1.4 D-4D (NLP10_) ­10.01 - 09.05 55 ­75 1364 Hatchback

TOYOTA YARIS VERSO (_P2_) 1.3 (NCP20_, NCP22_) ­11.02 - 09.05 62 ­84 1299 MPV

TOYOTA YARIS VERSO (_P2_) 1.3 (NCP20_, NCP22_) ­08.99 - 10.02 63 ­86 1299 MPV

TOYOTA YARIS VERSO (_P2_) 1.5 (NCP21_) ­03.00 - 09.05 77 ­105 1497 MPV

TOYOTA YARIS VERSO (_P2_) 1.5 (NCP21_) ­03.00 - 09.05 78 ­106 1497 MPV

Item Name: Control Arm Trailing Bushing

OEM Numbers: 1414.80 / 3520.Q2 / 3520.Q2 S2 / 3521.L3 / 3521.L3 S2 / 48068-0H010 / 48068-0H010 S2 / 48069-0H010 / 48069-0H010 S2 / 48654-0H010 / 48654-16110

Outer diameter [mm]: 33 mm,33.1 mm,34 mm

Material: Elastomer

Weight [kg]: 0.106 kg

Inner Diameter [mm]: 12 mm,12.3 mm

Thickness [mm]: 53 mm

Color: Black

Fitting Position: Front Axle left and right,Lower,Front
